Neu BEAM 2.0 in Mailand, Lombardei, Italien
Neu
Doubleclick to zoom in
Weitere Fotos
und Informationen erhalten Sie auf Anfrage
Spezifikationen
- Zustand
- neu
- Flow rate (max)
- 1.0 l/min
- Outlet pressure (min)
- /
- Outlet pressure(max)
- 1.0 bar less than inlet pressure
- Total hydrocarbon content
- < 0.05ppm
- Start-up time
- 50 min
- Max inlet hydrocarbon content
- 100 ppm
- Min supply pressure
- 3 bars (43 psi)
- Max supply pressure
- 5 bar (72,5 psi)
- Dew point
- <3°C
- Temperature (min)
- 1 °C (34°F)
- Temperature (max)
- 35°C (95°F)
- Rs232
- Standard
- Supply voltage
- 100-240Vac 50/60Hz
- Connection type
- IEC320-C13
- Installation power (max)
- 240W (280VA)
- Fuse rating (5x20mm)
- 2A
- Dimensions
- Standard 19″ – 4U
- Net weight
- <13 kg
- Outlet port
- 6 mm Push-Fit
- Inlet port
- 6 mm Push-Fit
- Health connectot
- max 5A, 40VDC MAX / 24VAC MAX (NC)
- Temperature (min;max)
- 5-35°C (41-95°F)
- Humidity (max, non condensing)
- 80% at 25°C (77°F)
- Noise
- <25dB (A)
- Ip rating
- IP20
- Kategorie
- Stromaggregate in Italien
- Subkategorie
- Premium gasgeneratoren
- Inserat-ID
- 59850334
Beschreibung
The BEAM 2.0 performs in 24/7 production process worldwide with utmost reliability. Even under the most challenging environments BEAM 2.0 guarantee frictionless industrial use for different applications (example: high power UV-lasers (>300 nm)). The Generator produces a continuous flow of hydrocarbon-free air. The flow is controlled stable. All Generators reduce the total quantity of hydrocarbons to less than 0,01 ppm, establishing a stable flow for your application. Zero-air produced in this way replaces existing stocks of synthetic air stored in high pressure bottles.Laser Gas Generators are designed specifically to supply clean, dry, hydrocarbon-free air to be used for several applications.LNI Swissgas recognizes the importance of having a safe, reliable and cost-effective supply of high-purity Zero addition, providing flexibility to add or remove modules as your application requirements evolve over time.
