Gebraucht Wavetek 278 in Darmstadt, Hessen, Deutschland
Gebraucht
Doubleclick to zoom in
Weitere Fotos
und Informationen erhalten Sie auf Anfrage
Spezifikationen
- Zustand
- gebraucht
- 1978). numeric input is entered in free format
- fixed,
- Kategorie
- Testgeneratoren in Deutschland
- Subkategorie
- Funktionsgeneratoren
- Inserat-ID
- 90748211
Beschreibung
The Model 278, a 0.01 Hz to 12 MHz Programmable
Synthesized Function Generator, can operate in con-
tinuous, triggered, gated, burst, synthesized, external
reference, or external phase lock modes with output
levels to 20 volts peak-to-peak.
The synthesized mode has 5 digits of frequency
resolution with 0.0005% accuracy, or it can be locked
to an external 10 MHz (zero-crossing or TTL) fre-
quency reference for greater accuracy and stability.
In addition, the separate synthesizer circuit acts as a
highly accurate internal trigger source.
The generator can produce sine, triangle, square,
square complement, and pulse waveforms as well as
dc and external width..
Data entry is from the front panel or GPIB (IEEE-488,
floating, or exponential notation. Parameters may be
entered in any order. Internally, all entries are interac-
tively checked for errors and displayed on the front
panel, or they may be accessed through the GPIB.
Bewertungen
$1,055 USD
